Engineered with a fine two over five shed SSB triple layer construction, the PRINT SSB60205YM65-360CFM incorporates a 2 to 1 CD yarn ratio with paired binding yarns on the paper side for enhanced sheet support and layer integration. The very fine plain weave top surface maximizes fiber support and retention while delivering very high sheet support for superior formation quality. High open area enables excellent drainage capacity for efficient water removal. The fabric exhibits high MD and CD stiffness for outstanding dimensional stability, remaining dynamically stable under varying machine loads and speeds. Medium diameter yarns provide good wear potential. Excellent sheet release and good printability make this fabric ideal for high-quality printing papers.

Key Features

High open area for high drainage capacity.
High MD and CD stiffness for dimensional stability for dynamicall stable under load and speed.
Medium yarn diameter for good wear potential.

Product Parameters

Product Name	Forming Fabric PRINT SSB60205YM65
Material	Polyester monofilament
Function	Paper Machine
Application	Printing & Writing paper, Board Grades top layer, etc.
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weigh	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Application

Printing & Writing paper, Board Grades top layer, etc.

Etiketler:

Yüksek sıcaklığa dayanıklı kağıt makinesi kumaşı

sıcaklığa dayanıklı kağıt makinesi kumaşı

Yüksek sıcaklıkta kağıt makinesi şekillendiren kumaş

İlişkili Ürünler

SSB Triple Layer Paper Machine Cloth with 3 to 2 CD Yarn Ratio and Long Float Wear Side for Excellent Wear Potential and Dimensional Stability

En İyi Fiyatı Alın

SSB Triple Layer Forming Fabric with Plain Weave Top and Eight Shed Wear Side Featuring Low Wire Mark and Excellent Retention for Quality Papers

En İyi Fiyatı Alın

SSB Triple Layer Paper Making Forming Fabric with Plain Weave Paper Side and Eight Shed Wear Side Offering High Sheet Support and Drainage

En İyi Fiyatı Alın

SSB Triple Layer Paper Making Forming Fabric PRINT SSB60205YM61 with Two over Five Shed Shute Binding for Very High Sheet Support

En İyi Fiyatı Alın

SSB Forming Fabric with Two over Five Shed Shute Binding Structure Providing High Drainage and Minimal Wire Mark for Quality Papers

En İyi Fiyatı Alın

Ürün ayrıntıları

Evde > Ürünler >

Kumaşların şekillendirilmesi

Triple Layer Forming Fabric with High MD and CD Stiffness for Dimensional Stability and Medium Yarn Wear Resistance Featuring SSB Weave Design

Tüm Kategori

Triple Layer Forming Fabric with High MD and CD Stiffness for Dimensional Stability and Medium Yarn Wear Resistance Featuring SSB Weave Design

Marka Adı:	ATMC
Adedi:	1 adet
fiyat:	inquiry
Paketleme Ayrıntıları:	Standart ihracat kontrplak ahşap kasa
Ödeme Şartları:	L/C,D/A,D/P,T/T

Ayrıntılı Bilgiler

Ürün Tanımı

Ayrıntılı Bilgiler

Marka adı:

ATMC

Atkı Çapı (mm):

kırılma gücü:

Ağırlık (GSM):

Desen açıklaması:

Hava geçirgenliği:

Drenaj Endeksi (DI):

Çözgü / atkı malzemesi:

Açık Alan:

Yapı:

Kaliper (mm):

Fiber Destek Endeksi (FSI):

Kumaş rengi:

Ağ × Sayısı (l/cm):

Çözgü Çapı (mm):

Min sipariş miktarı:

1 adet

Fiyat:

inquiry

Ambalaj bilgileri:

Standart ihracat kontrplak ahşap kasa

Teslim süresi:

5-8 çalışma haftası

Ödeme koşulları:

L/C,D/A,D/P,T/T

Vurgulamak:

Triple Layer Forming Fabric with SSB weave

High MD CD stiffness forming fabric

Medium yarn wear resistance fabric

Ürün Tanımı

Triple Layer Forming Fabric with High MD and CD Stiffness for Dimensional Stability and Medium Yarn Wear Resistance Featuring SSB Weave Design

Key Features

High open area for high drainage capacity.
High MD and CD stiffness for dimensional stability for dynamicall stable under load and speed.
Medium yarn diameter for good wear potential.

Product Parameters

Product Name	Forming Fabric PRINT SSB60205YM65
Material	Polyester monofilament
Function	Paper Machine
Application	Printing & Writing paper, Board Grades top layer, etc.
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weigh	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Application

Printing & Writing paper, Board Grades top layer, etc.
