Designed as a two over five shed SSB triple layer fabric, the PRINT SSB60205YF68-400CFM features a 2 to 1 CD yarn ratio that optimizes the balance between support and drainage. The very fine plain weave paper side provides maximized fiber support for good retention and very high sheet support. High open area enables excellent drainage capacity, allowing rapid water removal without compromising formation quality. The fabric delivers formation improvements and good printability for superior end-product appearance. Medium diameter yarns contribute to good wear potential, while high MD and CD stiffness ensure dimensional stability under dynamic machine conditions.

Key Features

Two-shed paper side with paired CD binding yarns
Independent layers securely bound together
Very fine plain weave top surface

Product Parameters

Product Name	Forming Fabric PRINT SSB60205YF68
Material	Polyester monofilament
Function	Paper Machine
Application	Printing & Writing paper, Board Grades top layer, etc.
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weigh	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Application

Printing & Writing paper, Board Grades top layer, etc.
